Removing the trunnion adaptor (Axiom+ 7 only)

Before attempting to flush or surface mount an Axiom+ 7 display, the pre-fitted trunnion adaptor must first be removed from the rear of the unit.

Removing trunnion adaptor

In order to remove the pre-fitted trunnion adaptor:

1. Unscrew and remove the 4x M5x16 screws using a 4 mm hex wrench (Allen key).
2. Pull the trunnion adaptor away from the rear of the display.
