Audio app settings menu

Balance

Allows you to control the left / right speaker balance of your entertainment system speakers.

• L = Left speakers up to 100%

• Left = Right (Balance centered)

• R = Right speakers up to 100%

Fade

Allows you to control the front / back speaker fade of your entertainment system speakers.

• F = Front speakers up to 100%

• Front = Back (Fade centered)

• R = Rear speakers up to 100%

Crossover (Low pass filter):

Allows you to select the crossover frequency. The Low Pass Filter (LPF) will block all audio frequencies above the threshold you specify. Selecting APF (All Pass Filter) will allow all frequencies.

• 60 Hz

• 80 Hz

• 120 Hz

• APF

Crossover (High pass filter):

Allows you to select the crossover frequency. The High Pass Filter (HPF) will block all audio frequencies below the threshold you specify. Selecting APF (All Pass Filter) will allow all frequencies.

• 60 Hz

• 80 Hz

• 120 Hz

• APF

Multi-zone volume control:

Audio app Multi-zone control

Allows you to select independent audio zones that are controlled by multi-zone volume control.

• Audio zones 1–12

Reset:

Audio app Reset

Performs a factory reset and power cycle of the SR200.

• Reset

Diagnostics mode:

Audio app Diagnostics mode

Displays the SR200’s diagnostic information.

• Display diagnostics

Data Overlays

Enables configuration of Data overlays

Edit split ratio

Enables you to customize the position of the partitions in splitscreen app pages.
