Chart modes

The Chart app provides preset modes that can be used to quickly set up the Chart app for your intended use.

Chart,ModesTo change chart mode select the required mode from the app menu.


	SIMPLEChartSimple mode Simple mode suppresses chart detail to provide a clearer, simpler view for general orientation. In simple mode only navigation-related menu options are available. Changes made to settings are not saved in simple mode.
	DETAILEDChartDetailed mode Detailed mode is the default mode. Full chart details and menu options are available. Changes made to settings are saved.
	FISHINGChartFishing mode Fishing mode optimizes the Chart app for fishing. If supported by your cartography, fishing mode also displays more detailed contour lines. Full menu options are available. Changes made to settings are saved.
	RUNNINGChartRunning mode Running mode optimizes the Chart app for fast running. In running mode, chart detail is suppressed and full vessel offset is applied. This provides a clearer view ahead, which is ideal for faster running conditions. Full menu options are available. The Chart app can be configured to enter running mode automatically when vessel speed exceeds 10 knots. Changes made to settings are saved.
	TIDESChartTides In Tides mode, tide and current station icons are replaced with graphics representing tide and current conditions. Animation controls are displayed that enable playback of Tide and Current predictions over a 24 hour period. Tides mode also suppresses chart detail, to enhance the tide and current graphics. In this mode, set and drift vector graphics are displayed on the Chart around your vessel position.
