Product overview

NeuBoat Dock is a 6-camera surround-view system which combines the video feeds from all cameras to provide a 360° birds-eye view around your vessel to assist in docking maneuvers.

Product informationNeuBoat Dock

This intuitive view of your vessel surroundings significantly reduces the risks and complexities involved when maneuvering in tight-quarter environments, taking the stress out of vital maneuvers by creating a safer docking experience.

The NeuBoat Dock system is simple to calibrate, and does not require either Raymarine® personnel or additional calibration mats / posts to be present during the initial setup process. The system can be calibrated remotely, either via a Raymarine® Axiom MFD with a Wi-Fi Internet connection, or via a Raymarine® YachtSense Link Router.

The NeuBoat Dock system consists of 4 core components:

  1. Surround View Monitor (SVM) camera — located at the bow, blind-port, blind-starboard, port, starboard and stern positions on your vessel, the live video feeds from these cameras combine to provide a 360° birds-eye surround view of your vessel’s immediate surroundings.

  2. Camera Conversion Unit (CCU) — located below deck, this unit receives data from the 6 SVM cameras and then transmits the processed data to the connected Object Recognition Unit.

  3. Object Recognition Unit (ORU) — located below deck, this unit receives data from the Camera Conversion Unit and then interprets the visual information from all connected cameras into a synchronized view.

  4. Compatible multifunction display (MFD) — located either above or below deck, this system component receives data from the Object Recognition Unit and displays it in the NeuBoat Dock app. For operation instructions, refer to the dedicated NeuBoat Dock Operation Instructions (81418) document.
