Available data items

Engine page

Yamaha appYamaha appdata itemsYamaha appEngine page

Cell 1 and Cell 2

Data type

Data item

Data type

Data item

DepthDepth dataDataDepth

  • Depth

 EnvironmentEnvironment dataDataEnvironmental

  • Water Temp

DistanceDistance dataDataDistance

  • Trip

 GPSGNSS (GPS) dataDataGNSS (GPS)

  • SOG

EngineEngine dataDataEngine

  • Engine Trip Hours

  • Engine Hours

 PilotPilot dataDataPilot

  • Rudder

FuelFuel dataDataFuel

  • Engine economy total

  • Fuel flow total

  • Fuel used (trip)

  • Est. fuel remaining

 SpeedSpeed dataDataSpeed

  • STW

Cell 3

Cell 4

Data type

Data item

Data type

Data item

EngineEngine dataDataEngine

  • Coolant Temp

  • Coolant Pres

  • Alternator Level

  • Alternator

  • Oil Pres

 BoatBoat dataDataBoat

  • Accessory voltage level

  • Accessory voltage

  • Supply voltage level

  • Supply voltage

Yamaha appData page

Data type

Data item

Data type

Data item

BatteryBattery dataDataBattery

  • TTZ

  • SOC

 GPSGNSS (GPS) dataDataGNSS (GPS)

  • COG

  • Avg SOG

  • Max SOG

  • SOG

  • Loran Position

  • Position

  • COG SOG

BoatBoat dataDataBoat

  • Mast Rot

  • Roll

  • ROT

 HeadingHeading dataDataHeading

  • Lock Hdg Err

  • Tack Heading

  • Lock Hdg

  • Heading

  • Heading & STW

DepthDepth dataDataDepth

  • Max Depth

  • Min Depth

  • Depth

 NavigationNavigation dataDataNavigation

  • VMG to Wpt

  • BTW & DTW

  • CMG & VMG to WPT

  • Compass

  • BTW

  • XTE

  • DTW

  • CMG

  • DMG

  • Wpt ETA

  • TTP

  • Target Pos

  • Loran Target Pos

  • Wpt TTG

  • Wpt

  • Rte ETA

  • Next turn angle

  • Origin target distance

  • Next waypoint name

  • BOTW

DistanceDistance dataDataDistance

  • Trip season

  • Trip month

  • Trip day

  • Trip manual

  • Ground Log

  • Trip

  • Log

 PilotPilot dataDataPilot

  • Rudder

EngineEngine dataDataEngine

  • RPM

  • Engine Trip Hours

  • Fuel Rate (Avg)

  • Inst Fuel Economy

  • Engine Fuel Rate

  • Engine Hours

 SpeedSpeed dataDataSpeed

  • VMG to Wind

  • Avg STW

  • Max STW

  • STW

FuelFuel dataDataFuel

  • Engine economy total

  • Fuel flow total

  • Time to empty

  • Distance to empty

  • Fuel used (season)

  • Total Trip Fuel

  • Fuel used (trip)

  • Est. fuel remaining

 TimeTime dataDataTime

  • Timer

  • Sunset Time

  • Sunrise Time

  • UTC Time

  • Local Time

  • UTC Date

  • Local Date

  • Time and Timer

EnvironmentEnvironment dataDataEnvironmental

  • Drift from ps

  • Wind Chill (App)

  • Wind Chill (True)

  • Dew Point

  • Max Air Temp

  • Min Water Temp

  • Water Temp

  • Set

  • Drift

  • Sunrise/Sunset

  • Set Drift

 WindWind dataDataWind

  • Max AWA

  • GWD + Beaufort

  • TWA & TWS

  • TWA (CH) & TWS

  • TWA & VMG to Wind

  • AWA & AWS

  • AWA (CH) & AWS

  • AWA & VMG to Wind

  • GWS & GWD

  • AWS

  • Max AWS

  • Min AWS

  • AWA

  • AWA (CH)

  • Cardinal Wind

  • Min AWA

  • TWS

  • Min TWS

  • Max TWS

  • TWA

  • TWA (CH)

  • Max TWA

  • Min TWA

  • TWD

  • GWS

  • GWD

  • Beaufort (wind force scale)

Yamaha appTanks page

Data type

Data item

Data type

Data item

BoatBoat dataDataBoat

  • Fresh Water

  • Live Well

  • Gray Water

  • Black Water

 FuelFuel dataDataFuel

  • Total Fuel (vol)

  • Total Fuel

  • Fuel level
